ATP8900plus is self-designed handheld FT-IR device with compact design fit to field application. It features a complete software functions and attachments, unique designs plug and play to measure modules and attachments in efficiency. Easy to operate software can satisfy any measure and analysis in the field.
It's widely applied to online in real time monitor industrial gases, identify unknown narcotics , drugs and explosives by force enforcement , identify oil product quality, manufacturer , and gemstones classification , and gemstones classification , relics and museum antiques.
ATP8900plus has strictly satisfied standards of Design Qualification, Installation qualification, Operation Qualification and Performance Qualification verification.
Selection Guide | |
Model | Description |
ATP8900Plus-ST | Transmission module for solid |
ATP8900Plus-LT | Transmission module for liquid |
ATP8900Plus-ATR-Diamond | Diamond ATR module |
ATP8900Plus-ATR-Diamond-120° | Heated diamond ATR module |
ATP8900Plus-ATR-ZnSe-1 | ZnSe ATR module / Single |
ATP8900Plus-ATR-ZnSe-5 | ZnSe ATR module / 5 times |
ATP8900Plus-ATR-Ge | Ge ATR module |
ATP8900Plus-DR-UP | Upward diffuse reflection |
ATP8900Plus-DR-F | Front diffuse reflection |
ATP8900Plus-SR-30 | 30 Degree Specular reflection |
ATP8900Plus-GC | Equipped with gas cell |
ATP8900Plus-Laptop | Equipped touchscreen desktop |
Key Parameters
ꔷ Michelson interferometer with wear free and reliability of 10 year guaranty, with cube-corner mirror resist mechanical and temperature vibration
ꔷ Higher stability of optical system is designed with gold mirror improve reflectivity by >5% than traditionalaluminum mirror.
ꔷ Super sensitivity and reliable temperature controlled DTGS detectors
ꔷ Reliable performance of solid laser life up to 10 years
ꔷ Vacuum cooling ceramic IR light source with high performance
Features:
ꔷ Mobility: compact size and easy to carry to take in lab, car , any field place.
ꔷ Flexibility: A complete functions of sample?modules and attachments for flexible replacement in few seconds
ꔷ Intelligent: Auto identify sample?module and attachment provides real time monitor
ꔷ Stability: Permanent vertical interferometer module?wear-free and resistance of?shocks?, vibrations and temperatures?
ꔷ Reliability: Metallic housing resists electric magnet interference obtaining reliable result
ꔷ User-friendly: Easy-to-operate interface for non-expert and expert users
Application:
ꔷ Environmental industry:
FTIR has been widely applied to environmental monitor, environmental chemistry, and environmental pollution.FTIR can online monitor gas pollution of H2O , NOX(NO2 , NO , N2O) , HF, SO2, CO,?HCl ,NH3 , CO2 etc. Particles in air pollution and their types and concentration. It also can monitor environmental equipment, say vacuum cleaner,? desulfurization and depickle equipment.
ꔷ Criminal investigation:
Fast detect explosives export field evidence in dangerous site, black powder, nitrolite, TNT, hexogen , PETN...
ꔷ Drugs enforcement:
drugs screen morphine, heroin, Cocaine, Ice (crystal methamphetamine), Ketamin, new psychoactive substances (nps)
ꔷ True/Fake, quality qualified/disqualified, manufacturer's lubricating oil identification
ꔷ Classification and identification of gemstones and jade
ꔷ QC check, materials compliant with standards or not.
ꔷ Identify unknown materials, if the pollution to the material detected can be auto match in the library and know the pollution material name.
Advantages To Monitor Gas
ꔷ No necessary to adjust cell in front of sample, Nitrogen calibration improves efficiency
ꔷ Permanent vertical interferometer module provides excellent shock and temperature resistant ensure reliability
ꔷ ZnSe-made beam splitter and mirror seal dehumidifying designed to operate in the field and at site
ꔷ Gas cell optical path allow customize by user own base on their specific concentration.
ꔷ Built-in temperature control system to keep the constant performance under different conditions
ꔷ Optional quality & flow controller for high concentration inlet sample and linearity calibration
ꔷ Built-in GTG sensor ( optional MCT ) stand severe environment
