Online Spectroradiometer
ATP9110OL
EXW
1 unit
Made in China
The wavelength range is up to 300~11000nm, suitable for geological research, mineral exploration, remote sensing, crop monitoring, forest research, oceanography and other fields of application.
Quantity
Description
ATP9110OL Online Broadband Fieldspec Spectroradiometer (Fieldspec) is a new portable fieldSpec from Optosky. The wavelength range is up to 300~11000nm,suitable for geological research, mineral exploration, remote sensing, crop monitoring, forest research, oceanography and other fields of application.
ATP9110OL series can be unattended for a long time, work continuously for several months, powered by solar panels, and built-in 32G memory, which can be transmitted to the central control room through 4G Internet of Things Online monitoring for months. It employs high performance, fast and accurate measurement, easy to operate and held etc. It's configured powerful software package, and applied to measurement of reflectance, radiometry, photometry and colorimetry.
Features
Applications
ATP9110OL Online Broadband Fieldspec Spectroradiometer (Fieldspec) is a new portable fieldSpec from Optosky. The wavelength range is up to 300~11000nm,suitable for geological research, mineral exploration, remote sensing, crop monitoring, forest research, oceanography and other fields of application.
ATP9110OL series can be unattended for a long time, work continuously for several months, powered by solar panels, and built-in 32G memory, which can be transmitted to the central control room through 4G Internet of Things Online monitoring for months. It employs high performance, fast and accurate measurement, easy to operate and held etc. It's configured powerful software package, and applied to measurement of reflectance, radiometry, photometry and colorimetry.
| Model | Features |
| ATP9110OL-25 | Fair resolution，300~2500nm |
| ATP9110OL-25H | High resolution，300~2500nm |
| ATP9110OL-17 | High resolution，300~1700nm |
| ATP9110OL-50 | High resolution，300~5000nm |
| ATP9110OL-11000 | High resolution，300~11000nm |
Features
Online fieldspec spectroradiometer, real-time monitoring for a long time
Maximum broad spectral range: 300-11000nm
High sensitivity, detector quantum efficiency reach up to 60%, NIR sensitivity is 40% higher than traditional PDA detector
Fast measure speed, one sampling time< 10ms
Solar-skylight real-time monitoring and compensation
Directly powered by solar cells
4G, WIFI
Dynamic dark current correction, reduce noise
Display probe inclined angles, laser indicator indicates probe direction, easy to adjust
PC software control mode
Applications
Geological research, prospecting
Meteorological monitoring
Remote sensing measurement
Crop monitoring
Forest research, oceanographic research
