Description:
LIBS is a type of optical emission spectroscopy used to meausre elemental concentrations in a material. LIBS operates by using a pulsed, focused laser that is fired at a sample with sufficient pulse energy as to create a plasma around the area struck. Bound atomic electrons are striped from the atoms comprising the material. As the plasma cools, atoms recombine with electrons and in the process emit light in the UV, optical and IR regimes.
LIBS has been used for more than 20 years as a laboratory benchtop technique, capable of analyzing any element in the periodic table, LIBS can analyze any elements in the periodic table. In resent years, LIBS technique has been miniaturized into a handheld device used in a wide application.
Features:
Based on laser technology
PMI including carbon and silicon
Get a reading in under 1 minute
Argon protection gas needed
Lightweight, at 3.9 lbs with battery
Intuitive GUI, minimal training needed
CE,IC,RoHS, IP54 certified
Parameters
Technology |
Laser-induced breakdown spectroscopy(LIBS) |
Dimension |
~3.6*11*5.9 in |
Weight |
3.9 lbs including battery and argon |
Battery |
Lithium-ion battery, 14.8V, 3250mAh |
IP rating |
IP54 |
WIFI |
802.11b/g/n/a, supports 2.4 and 5.0GHz |
Bluetooth |
Bluetooth 4.1, BLE |
Display |
4.0-inch touch screen, brightness adjustable |
Internal storrage |
16Gb |
Laser |
Class 3B, 1064nm, passive Q-switched DPSS laser |
Spectrometer |
<0.1nm resolution |
Camera |
Integrated macro camera |
Alloy base |
Alloy steel,carbon steel, stainless |
Element capability |
Ai, C, Co, Cr, Cu, Fe, Mn, Mo, Ni, Si, Ti, W |
Argon gas |
Purity:99.99% or higher |
Temperature range |
0~40℃ storage, 5~35℃ operation |
Software |
Software v8.5 |
Argon |
Purity:99.99% or greater, Pressure:<8MPa or <1000psi |
Library |
UNS based, highly customizable |
Warranty |
One year factory warrantly on all parts |
Cost |
Among the most competitive |
Other features |
Easy to use, no extensive training needed safety, laser interlock, safety harness strap spot calibration function |
Maintenance |
Sapphire window cleaning using a cotton swap; Accuracy check/calibration using standard samples |
Acessories |
Bluetooth thermal printer, Battery-operated grinde Solicone protective sleeve, Leather protective sleeve Wifi router Two-position metal stand Curved face plates for measuring pipes Small fixtures for measuring welding rods Safety harness strap, Vertical test stand Compact storm case with custom foam insert |
