VIS-NIR Hyperspectral Camera

VIS-NIR Hyperspectral Camera

Model NO. ATH1010-4-25

Delivery FOB

minimum order 1 unit

Country of Origin Made in China

ATH1010-4-25 is a new and optimized shortwave infrared hyperspectral imaging system with small size and light weight. The spectral range is 400 ~ 2500nm. Except, ATH1010-4-25 has high spatial resolution, high spectral resolution, wide imaging range, etc. And it consists of two parts: imaging lens and hyperspectral camera.

Quantity

Contact Now add to cart

Describe:
ATH1010-4-25is a new and optimized shortwave infrared hyperspectral imaging system with small size and light weight.The spectral range is 400 ~ 2500nm. Except,  ATH1010-4-25  has  high  spatial  resolution, high spectral resolution,wide imaging range,etc.And it consists of two parts:imaging lens and hyperspectral camera.
ATH1010-4-25uses high-performance Te-cooled CCD imaging device with 2048x 1200pixels and 640 x 512pixels,which makes it has clear image,less noise and good linearity.
With  its  temperature-stable    optical    system, ATH1010-4-25    provides    excellent    stability    and sensitivity   required   in   VIS-NIR   infrared   chemical imaging    applications,   and    meets    the    stringent requirements of  laboratory,    field,    and    industrial applications,   making   it   become   the   right-hand   in applications such as drug quality inspection,food safety, and agricultural analysis.



Feature：
    Spectral Range ：380 ~ 2500 nm
   Max Spatial Channels  ：2048
   Max Spectral Channels  ： 1200
   Max FOV ：21.7°(Depending on the lens)
    Superior imaging performance
   Data format is compatible with ENVI;
   Dimensions ：372mm × 276mm × 185mm；
   Light weight：4.56kg；
   No mechanical scanning,high reliability;

Application：
Prospecting for geology and minerals;
Agriculture Monitoring:Crop condition and yieldassessment
Forest pest and fire prevention monitoring； Coastline and ocean monitoring；
Pasture monitoring；
Lake and watershed monitoring；
Remote sensing teaching and research  ；
Industrial sorting；
Ecological environment protection and mine monitoring；
Water quality and soil monitoring；

1.Selection Guide

ATH1010 Series Model	Feature	Application
ATH1010	380- 1000nm VIS-NIR Hyperspectral Camera	Precision agriculture, agroforestry diseases and insect pests,vegetation analysis, planting area assessment, crop yield assessment,water quality analysis, art scanning, cultural relic identification,pattern scanning,industrial sorting, oil pollution detection, etc
ATH1010- 17	1.0~ 1.7μm SWIR        Hyperspectral Camera	Semiconductor, industrial sorting, food sorting, construction waste sorting, meat sorting, plastic sorting, geological exploration, mineral exploration,   cultural relics identification, judicial
ATH1010-25	1.2~2.5μm SWIR        Hyperspectral Camera	Precision agriculture and food analysis, dark plastic sorting,geological exploration, mineral exploration, national defense industry, cultural relic identification, judicial identification, document inspection, water content，analysis, drug and material sorting, mineral mapping, medical identification, waste recycling;
ATH1010-4-25	0.38~2.5μm VIS-NIR Hyperspectral Camera	Geological survey, national defense industry, gas analysis, VOCs inspection,water temperature detection, land cover type identification,camouflage investigation, mineral sorting,
ATH1010-04- 17	0.38~ 1.7μm VIS-NIR Hyperspectral Camera	Precision agriculture, agroforestry diseases and insect pests, vegetation analysis, planting area assessment, crop yield assessment, water quality analysis, art scanning, cultural relic identification, pattern scanning,industrial sorting, oil pollution detection, etc

2. Performance Parameter



ITEM	PARAMETER
Spectral Range	380 ~ 2500 nm
	VNIR	SWIR
Sensor Type	High Sensitivity VNIR detector	Te-cooled InGaAs I and InGaAs II SWIR Detector
Resolution	1.3 nm	8- 15 nm
Image Resolution	2048 × 1088	640 X 512
Raw Pixels Size	5.5 µm x 5.5 µm	15 µm x 15 µm
Bit Depth	12bits	16bits
Max Spatial Channels	1200	512
Max Spectral Channels	2048	2048
Frame Rate	240 fps	240 fps
Interface	USB3.0
Power Supply	12V± 10% ，70W
FOV	15.2°@f=35mm
IFOV	0.7mrad@f=35mm
Size	372mm × 276mm ×185mm
Weight	<4.56kg
Working Temp.	-20 - 50°C
Storage Temp.	-30-70°C

Datasheet Download:

ATH1010-4-25_VIS-NIR Hyperspectral Camera_Datasheet_20220712.pdf
