Online Rotary Scan Hyperspectral Imaging System
ATH3010OL
EXW
1
Made in China
ATH3010OL is an online rotary scan hyperspectral imager. In addition to waterproof and dustproof, online monitoring, ATH3010OL has the characteristics of high spatial resolution, high spectral resolution, wide imaging range, etc.
Quantity
Description:
ATH3010OL is an online rotary scan hyperspectral imager. In addition to waterproof and dustproof, online monitoring, ATH3010OL has the characteristics of high spatial resolution, high spectral resolution, wide imaging range, etc.
ATH3010OL consists of two parts: hyperspectral imager and fully automatic motorized rotating stage, where the high spectrometer is based on high-efficiency transmission grating technology and has good aberration characteristics.
ATH3010OL uses 2048×1088 or 2048×2048 pixel high performance CCD imaging device, imaging clearly, less noise; Internal integration of the original high compression ratio image compression algorithm.
ATH3010OL is mounted on a pole and adds automatic calibration devices, weather monitoring sensors, etc., to enable long, large area scanning of the target, unattended operation, and continuous operation for several months.
Features：
● High-sensitivity hyperspectral imager
● 360° full-angle scan, adjustable pitch Angle
●A variety of focal length objective lenses are available to adapt to different focusing targets
● Optical design with high image quality at the full target surface, and the spot diameter is less than 0.5 pixels
● 5-megapixel visible light camera with integrated spectruml
● With automatic wiper, keep Windows clean, automatic heater, window defrost and defog, and shade hood
●Sets several preset bits and an automatic scan trajectoryl
●The objective interface is standard C-mount, allowing you to change the objective according to user requirements, and the focal length of the lens ranges from 16 to 140mml
●Maximumspectralrange: 400-1000nm, 900-1700nm, 400-1700nml
●Maximum FOV Angle: 31.7°
Application：
●Monitor Agriculture: plant diseases and insect
pest, disaster, categoriesl
●Forestry: Tree categories identification, Phytomass, nutrient elements, forest health etc.
●Water Environment: Water quality parameters, water waste spatial distribution and migration analysis
●Soil pollution: heavy metal waste
●Minerals: Mineral mapping, ingredients explore, metallogenic prognosis etc.
●City：Urban planning, road monitoring, landscape vegetation monitoring, environmental protection
ATH3010OL is an online rotary scan hyperspectral imager. In addition to waterproof and dustproof, online monitoring, ATH3010OL has the characteristics of high spatial resolution, high spectral resolution, wide imaging range, etc.
ATH3010OL consists of two parts: hyperspectral imager and fully automatic motorized rotating stage, where the high spectrometer is based on high-efficiency transmission grating technology and has good aberration characteristics.
ATH3010OL uses 2048×1088 or 2048×2048 pixel high performance CCD imaging device, imaging clearly, less noise; Internal integration of the original high compression ratio image compression algorithm.
ATH3010OL is mounted on a pole and adds automatic calibration devices, weather monitoring sensors, etc., to enable long, large area scanning of the target, unattended operation, and continuous operation for several months.
| Model | Features |
| ATH3010OL | Online hyperspectral，Spectral Range：400-1000nm，Unattended |
| ATH3010OL-17 | Online hyperspectral ，Spectral Range：900-1700nm，Unattended |
| ATH3010OL-4-17 | Online hyperspectral ，Spectral Range：400-1700nm，Unattended |
Features：
● High-sensitivity hyperspectral imager
● 360° full-angle scan, adjustable pitch Angle
●A variety of focal length objective lenses are available to adapt to different focusing targets
● Optical design with high image quality at the full target surface, and the spot diameter is less than 0.5 pixels
● 5-megapixel visible light camera with integrated spectruml
● With automatic wiper, keep Windows clean, automatic heater, window defrost and defog, and shade hood
●Sets several preset bits and an automatic scan trajectoryl
●The objective interface is standard C-mount, allowing you to change the objective according to user requirements, and the focal length of the lens ranges from 16 to 140mml
●Maximumspectralrange: 400-1000nm, 900-1700nm, 400-1700nml
●Maximum FOV Angle: 31.7°
Application：
●Monitor Agriculture: plant diseases and insect
pest, disaster, categoriesl
●Forestry: Tree categories identification, Phytomass, nutrient elements, forest health etc.
●Water Environment: Water quality parameters, water waste spatial distribution and migration analysis
●Soil pollution: heavy metal waste
●Minerals: Mineral mapping, ingredients explore, metallogenic prognosis etc.
●City：Urban planning, road monitoring, landscape vegetation monitoring, environmental protection
