Fiber Center Diameter

200 μm, 400 μm or 600 μm

Fiber Center/Cover Material

silicon

Fiber bundling method:

6 outer layers of illumination fiber, 1 readout fiber in the middle

Optimum wavelength range

UV-VIS(180-1100nm)
VIS-NIR(400-2100nm)

Collar material

Stainless steel

Collar Size:

7.62 x 0.64 cm

NA

0.22

Illumination and readout fiber tail terminations

SMA905

Shell Material:

Blue PVC plastic reinforced with Keclar fibers

Temperature range

-20 °C~450 °C

Assembly Probe Length

2m (data collection and arrangement in the middle)
