Uncooled-4096 Ultra-high Resolution Spectrometer

Uncooled-4096 Ultra-high Resolution Spectrometer
ATP3334
FOB
1 unit
1unit / Month
China
1-monthDay
Quantity

Description:

  • ATP3334 Spectrometer is newly designed ultra thin, uncooled, ultra high resolution miniature spectrometers developed by Optosky. ATP3334 Spectrometer are M-type optical path structures, which have extraordinary ultra-high resolution. Uncooled 4096 pixels at the same time, it uses the linear array detector, reached the acme of the ultra high resolution, high resolution can reach <0.04 nm, suitable for all kinds of applications, high resolution and high reliability, ultra-high speed, low cost, high cost performance and other characteristics, can adapt to the online test uses a variety of environments such as micro Spectrometer.
  • ATP3334 spectrometer is uncooled, which greatly reduces the dark current and noise , improves the dynamic range and signal-to-noise ratio, and improves the environmental adaptability of the Spectrometer.
  • ATP3334 Spectrometer can receive SMA905 fiber input light or free space light, and output the spectral data obtained through USB2.0 or UART port.
  • ATP3334 Spectrometer has free SDK for customers self-developed, Optosky support C++, C#, Labview and Linux system SDK, which is very convenient for OEM customers to design solutions.


Feature

  • Wavelength range: 200-1100 nm;
  • Resolution: 0.04 ~ 3 nm;
  • Optical path: M-shape C-T;
  • Detector:  4096 pixel;
  • Integration time: 0.1ms ~ 256s;
  • Power supply: DC 5V power supply;
  • ADC:16 bit;
  • Output:USB Type-C;
  • 20-pin expansion interface;


Application

  • LIBS, Plasma luminescence detection;
  • Raman detection;
  • Wavelength monitoring, laser, LED and other luminous bodies
  • Water quality analyzer
  • LED sorting machine, color detection;
  • Spectral analysis, radiation spectroscopic analysis, spectrophotometric analysis;
  • Reflection and transmission spectrum detection
